74AHC74; 74AHCT74 Dual D-type flip-flop with set and reset; positive-edge trigger Rev. 8 — 22 April 2020 Product data sheet 1. General description The 74AHC74; 74AHCT74 is a high-speed Si-gate CMOS device and is pin compatible with Low-Power Schottky TTL (LSTTL). It is specified in compliance with JEDEC standard No. 7-A. The 74AHC74; 74AHCT74 is a dual positive-edge triggered, D-type flip-flop with individual data inputs (D), clock inputs (CP), set inputs (SD) and reset inputs (RD). It also has complementary outputs (Q and Q). The set and reset are asynchronous active LOW inputs that operate independent of the clock input. Information on the data input is transferred to the Q output on the LOW to HIGH transition of the clock pulse. The data inputs must be stable one set-up time prior to the LOW to HIGH clock transition for predictable operation. Schmitt-trigger action in the clock input makes the circuit highly tolerant to slower clock rise and fall times. 2. Features and benefits • Balanced propagation delays • All inputs have Schmitt-trigger actions • Inputs accept voltages higher than V CC • Input levels: • For 74AHC74: CMOS level • For 74AHCT74: TTL level • ESD protection: • HBM EIA/JESD22-A114E exceeds 2000 V • MM EIA/JESD22-A115-A exceeds 200 V • CDM EIA/JESD22-C101C exceeds 1000 V • Multiple package options • Specified from -40 °C to +85 °C and from -40 °C to +125 °C 3. Ordering information Table 1. Ordering information Type number Package Temperature range Name Description Version 74AHC74D -40 °C to +125 °C SO14 plastic small outline package; 14 leads; SOT108-1 body width 3.9 mm 74AHCT74D 74AHC74PW -40 °C to +125 °C TSSOP14 plastic thin shrink small outline package; 14 leads; SOT402-1 body width 4.4 mm 74AHCT74PW 74AHC74BQ -40 °C to +125 °C DHVQFN14 plastic dual in-line compatible thermal enhanced SOT762-1 very thin quad flat package; no leads; 14 terminals; 74AHCT74BQ body 2.5 × 3 × 0.85 mm

Nexperia 74AHC74; 74AHCT74 Dual D-type flip-flop with set and reset; positive-edge trigger 4. Functional diagram 1SD 4 SD 1D 1Q 2 D Q 5 1CP 3 CP FF 1Q Q 6 RD 4 4 10 S 5 1SD 2SD 1 1RD 3 C1 SD 10 2SD 2 1D 6 2 1D 1Q 5 1 R D Q 12 2D 2Q 9 SD 3 1CP CP 12 2D D Q 2Q 9 11 2CP 10 FF 2CP S 9 RD Q 12QQ 68 11 CPFF Q 2Q 8 1112 1CD1 8 1RD 2RD RD 13 R 1 13 mna418 13 2RD mna420 mna419 Fig. 1. Functional diagram Fig. 2. Logic symbol Fig. 3. IEC logic symbol Q C C C C C C D Q C C RD SD mna421 CP C C Fig. 4. Logic diagram (one flip-flop) 74AHC_AHCT74 All information provided in this document is subject to legal disclaimers. © Nexperia B.V. 2020. All rights reserved Product data sheet Rev. 8 — 22 April 2020 2 / 15

Nexperia 74AHC74; 74AHCT74 Dual D-type flip-flop with set and reset; positive-edge trigger 5. Pinning information 5.1. Pinning 74AHC74 74AHCT74 D C terminal 1 R C 1 V index area 1 14 1D 2 13 2RD 1CP 3 12 2D 74AHC74 74AHCT74 1SD 4 11 2CP 1Q 5 GND(1) 10 2SD 1RD 1 14 VCC 1Q 6 9 2Q 1D 2 13 2RD 7 8 1CP 3 12 2D D Q 1SD 4 11 2CP GN 2 001aac450 1Q 5 10 2SD Transparent top view 1Q 6 9 2Q (1) This is not a ground pin. There is no electrical or GND 7 8 2Q mechanical requirement to solder the pad. In case 001aac449 soldered, the solder land should remain floating or connected to GND. Fig. 5. Pin configuration SOT108-1 (SO14) and SOT402-1 (TSSOP14) Fig. 6. Pin configuration SOT762-1 (DHVQFN14) 5.2. Pin description Table 2. Pin description Symbol Pin Description 1RD 1 asynchronous reset direct input (active LOW) 1D 2 data input 1CP 3 clock input (LOW to HIGH, edge-triggered) 1SD 4 asynchronous set direct input (active LOW) 1Q 5 true flip-flop output 1Q 6 complement flip-flop output GND 7 ground (0 V) 2Q 8 complement flip-flop output 2Q 9 true flip-flop output 2SD 10 asynchronous set direct input (active LOW) 2CP 11 clock input (LOW to HIGH, edge-triggered) 2D 12 data input 2RD 13 asynchronous reset direct input (active LOW) V 14 supply voltage CC 74AHC_AHCT74 All information provided in this document is subject to legal disclaimers. © Nexperia B.V. 2020. All rights reserved Product data sheet Rev. 8 — 22 April 2020 3 / 15

Nexperia 74AHC74; 74AHCT74 Dual D-type flip-flop with set and reset; positive-edge trigger 6. Functional description Table 3. Function table H = HIGH voltage level; L = LOW voltage level; X = don’t care; ↑ = LOW to HIGH transition; Q = state after the next LOW to HIGH CP transition. n+1 Control Input Output nSD nRD nCP nD nQ nQ nQ nQ n+1 n+1 L H X X H L - - H L X X L H - - L L X X H H - - H H ↑ L - - L H H H ↑ H - - H L 7. Limiting values Table 4. Limiting values In accordance with the Absolute Maximum Rating System (IEC 60134). Voltages are referenced to GND (ground = 0 V). Symbol Parameter Conditions Min Max Unit V supply voltage -0.5 +7.0 V CC V input voltage -0.5 +7.0 V I I input clamping current V < -0.5 V [1] -20 - mA IK I I output clamping current V < -0.5 V or V > V + 0.5 V [1] -20 +20 mA OK O O CC I output current V = -0.5 V to (V + 0.5 V) -25 +25 mA O O CC I supply current - +75 mA CC I ground current -75 - mA GND T storage temperature -65 +150 °C stg P total power dissipation T = -40 °C to +125 °C [2] - 500 mW tot amb [1] The input and output voltage ratings may be exceeded if the input and output current ratings are observed. [2] For SOT108-1 (SO14) package: Ptot derates linearly with 10.1 mW/K above 100 °C. For SOT402-1 (TSSOP14) package: Ptot derates linearly with 7.3 mW/K above 81 °C. For SOT762-1 (DHVQFN14) package: Ptot derates linearly with 9.6 mW/K above 98 °C. 8. Recommended operating conditions Table 5. Operating conditions Symbol Parameter Conditions 74AHC74 74AHCT74 Unit Min Typ Max Min Typ Max V supply voltage 2.0 5.0 5.5 4.5 5.0 5.5 V CC V input voltage 0 - 5.5 0 - 5.5 V I V output voltage 0 - V 0 - V V O CC CC T ambient temperature -40 +25 +125 -40 +25 +125 °C amb Δt/ΔV input transition rise and fall rate V = 3.0 V to 3.6 V - - 100 - - - ns/V CC V = 4.5 V to 5.5 V - - 20 - - 20 ns/V CC 74AHC_AHCT74 All information provided in this document is subject to legal disclaimers. © Nexperia B.V. 2020. All rights reserved Product data sheet Rev. 8 — 22 April 2020 4 / 15

Nexperia 74AHC74; 74AHCT74 Dual D-type flip-flop with set and reset; positive-edge trigger 9. Static characteristics Table 6. Static characteristics At recommended operating conditions; voltages are referenced to GND (ground = 0 V). Symbol Parameter Conditions 25 °C -40 °C to -40 °C to Unit +85 °C +125 °C Min Typ Max Min Max Min Max 74AHC74 V HIGH-level V = 2.0 V 1.5 - - 1.5 - 1.5 - V IH CC input voltage V = 3.0 V 2.1 - - 2.1 - 2.1 - V CC V = 5.5 V 3.85 - - 3.85 - 3.85 - V CC V LOW-level V = 2.0 V - - 0.5 - 0.5 - 0.5 V IL CC input voltage V = 3.0 V - - 0.9 - 0.9 - 0.9 V CC V = 5.5 V - - 1.65 - 1.65 - 1.65 V CC V HIGH-level V = V or V OH I IH IL output voltage I = -50 μA; V = 2.0 V 1.9 2.0 - 1.9 - 1.9 - V O CC I = -50 μA; V = 3.0 V 2.9 3.0 - 2.9 - 2.9 - V O CC I = -50 μA; V = 4.5 V 4.4 4.5 - 4.4 - 4.4 - V O CC I = -4.0 mA; V = 3.0 V 2.58 - - 2.48 - 2.40 - V O CC I = -8.0 mA; V = 4.5 V 3.94 - - 3.80 - 3.70 - V O CC V LOW-level V = V or V OL I IH IL output voltage I = 50 μA; V = 2.0 V - 0 0.1 - 0.1 - 0.1 V O CC I = 50 μA; V = 3.0 V - 0 0.1 - 0.1 - 0.1 V O CC I = 50 μA; V = 4.5 V - 0 0.1 - 0.1 - 0.1 V O CC I = 4.0 mA; V = 3.0 V - - 0.36 - 0.44 - 0.55 V O CC I = 8.0 mA; V = 4.5 V - - 0.36 - 0.44 - 0.55 V O CC I input leakage V = 5.5 V or GND; - - 0.1 - 1.0 - 2.0 μA I I current V = 0 V to 5.5 V CC I supply current V = V or GND; I = 0 A; - - 2.0 - 20 - 40 μA CC I CC O V = 5.5 V CC C input V = V or GND - 3 10 - 10 - 10 pF I I CC capacitance 74AHCT74 V HIGH-level V = 4.5 V to 5.5 V 2.0 - - 2.0 - 2.0 - V IH CC input voltage V LOW-level V = 4.5 V to 5.5 V - - 0.8 - 0.8 - 0.8 V IL CC input voltage V HIGH-level V = V or V ; V = 4.5 V OH I IH IL CC output voltage I = -50 μA 4.4 4.5 - 4.4 - 4.4 - V O I = -8.0 mA 3.94 - - 3.80 - 3.70 - V O V LOW-level V = V or V ; V = 4.5 V OL I IH IL CC output voltage I = 50 μA - 0 0.1 - 0.1 - 0.1 V O I = 8.0 mA - - 0.36 - 0.44 - 0.55 V O I input leakage V = 5.5 V or GND; - - 0.1 - 1.0 - 2.0 μA I I current V = 0 V to 5.5 V CC I supply current V = V or GND; I = 0 A; - - 2.0 - 20 - 40 μA CC I CC O V = 5.5 V CC 74AHC_AHCT74 All information provided in this document is subject to legal disclaimers. © Nexperia B.V. 2020. All rights reserved Product data sheet Rev. 8 — 22 April 2020 5 / 15

Nexperia 74AHC74; 74AHCT74 Dual D-type flip-flop with set and reset; positive-edge trigger Symbol Parameter Conditions 25 °C -40 °C to -40 °C to Unit +85 °C +125 °C Min Typ Max Min Max Min Max ΔI additional per input pin; V = V - 2.1 V; - - 1.35 - 1.5 - 1.5 mA CC I CC supply current other pins at V or GND; CC I = 0 A; V = 4.5 V to 5.5 V O CC C input V = V or GND - 3 10 - 10 - 10 pF I I CC capacitance 10. Dynamic characteristics Table 7. Dynamic characteristics Voltages are referenced to GND (ground = 0 V); for test circuit, see Fig. 9. Symbol Parameter Conditions 25 °C -40 °C to -40 °C to Unit +85 °C +125 °C Min Typ [1] Max Min Max Min Max 74AHC74 t propagation nCP to nQ, nQ; see Fig. 7 [2] pd delay V = 3.0 V to 3.6 V; C = 15 pF - 5.2 11.9 1.0 14.0 1.0 15.0 ns CC L V = 3.0 V to 3.6 V; C = 50 pF - 7.4 15.4 1.0 17.5 1.0 19.5 ns CC L V = 4.5 V to 5.5 V; C = 15 pF - 3.7 7.3 1.0 8.5 1.0 9.5 ns CC L V = 4.5 V to 5.5 V; C = 50 pF - 5.2 9.3 1.0 10.5 1.0 12.0 ns CC L nSD, nRD to nQ, nQ; see Fig. 8 V = 3.0 V to 3.6 V; C = 15 pF - 5.4 12.3 1.0 14.5 1.0 15.5 ns CC L V = 3.0 V to 3.6 V; C = 50 pF - 7.7 15.8 1.0 18.0 1.0 20.0 ns CC L V = 4.5 V to 5.5 V; C = 15 pF - 3.7 7.7 1.0 9.0 1.0 10.0 ns CC L V = 4.5 V to 5.5 V; C = 50 pF - 5.3 9.7 1.0 11.0 1.0 12.5 ns CC L f maximum see Fig. 7 max frequency V = 3.0 V to 3.6 V; C = 15 pF 80 125 - 70 - 70 - MHz CC L V = 3.0 V to 3.6 V; C = 50 pF 50 75 - 45 - 45 - MHz CC L V = 4.5 V to 5.5 V; C = 15 pF 130 170 - 110 - 110 - MHz CC L V = 4.5 V to 5.5 V; C = 50 pF 90 115 - 75 - 75 - MHz CC L t pulse width CP HIGH or LOW; nSD, nRD LOW; W see Fig. 7 and Fig. 8 V = 3.0 V to 3.6 V 6.0 - - 7.0 - 7.0 - ns CC V = 4.5 V to 5.5 V 5.0 - - 5.0 - 5.0 - ns CC t set-up time nD to nCP; see Fig. 7 su V = 3.0 V to 3.6 V 6.0 - - 7.0 - 7.0 - ns CC V = 4.5 V to 5.5 V 5.0 - - 5.0 - 5.0 - ns CC t hold time nD to nCP; see Fig. 7 h V = 3.0 V to 3.6 V 0.5 - - 0.5 - 0.5 - ns CC V = 4.5 V to 5.5 V 0.5 - - 0.5 - 0.5 - ns CC 74AHC_AHCT74 All information provided in this document is subject to legal disclaimers. © Nexperia B.V. 2020. All rights reserved Product data sheet Rev. 8 — 22 April 2020 6 / 15

Nexperia 74AHC74; 74AHCT74 Dual D-type flip-flop with set and reset; positive-edge trigger Symbol Parameter Conditions 25 °C -40 °C to -40 °C to Unit +85 °C +125 °C Min Typ [1] Max Min Max Min Max t recovery nRD to nCP; see Fig. 8 rec time V = 3.0 V to 3.6 V 5.0 - - 5.0 - 5.0 - ns CC V = 4.5 V to 5.5 V 3.0 - - 3.0 - 3.0 - ns CC C power f = 1 MHz; V = GND to V [3] - 12 - - - - - pF PD i I CC dissipation capacitance 74AHCT74 t propagation nCP to nQ, nQ; see Fig. 7 [2] pd delay V = 4.5 V to 5.5 V; C = 15 pF - 3.3 7.8 1.0 9.0 1.0 10.0 ns CC L V = 4.5 V to 5.5 V; C = 50 pF - 4.8 8.8 1.0 10.0 1.0 11.0 ns CC L nSD, nRD to nQ, nQ; see Fig. 8 V = 4.5 V to 5.5 V; C = 15 pF - 3.7 10.4 1.0 12.0 1.0 13.0 ns CC L V = 4.5 V to 5.5 V; C = 50 pF - 5.3 11.4 1.0 13.0 1.0 14.5 ns CC L f maximum see Fig. 7 max frequency V = 4.5 V to 5.5 V; C = 15 pF 100 160 - 80 - 80 - MHz CC L V = 4.5 V to 5.5 V; C = 50 pF 80 140 - 65 - 65 - MHz CC L t pulse width CP HIGH or LOW; nSD, nRD LOW; 5.0 - - 5.0 - 5.0 - ns W V = 4.5 V to 5.5 V; CC see Fig. 7 and Fig. 8 t set-up time nD to nCP; V = 4.5 V to 5.5 V; 5.0 - - 5.0 - 5.0 - ns su CC see Fig. 7 t hold time nD to nCP; V = 4.5 V to 5.5 V; 0 - - 0 - 0 - ns h CC see Fig. 7 t recovery nRD to nCP; V = 4.5 V to 5.5 V; 3.5 - - 3.5 - 3.5 - ns rec CC time see Fig. 8 C power f = 1 MHz; V = GND to V [3] - 16 - - - - - pF PD i I CC dissipation capacitance [1] Typical values are measured at nominal supply voltage (VCC = 3.3 V and VCC = 5.0 V). [2] tpd is the same as tPLH and tPHL. [3] CPD is used to determine the dynamic power dissipation (PD in μW). PD = CPD × VCC2 × fi × N + Σ(CL × VCC2 × fo) where: fi = input frequency in MHz; fo = output frequency in MHz; CL = output load capacitance in pF; VCC = supply voltage in V; N = number of inputs switching; Σ(CL × VCC2 × fo) = sum of the outputs. 74AHC_AHCT74 All information provided in this document is subject to legal disclaimers. © Nexperia B.V. 2020. All rights reserved Product data sheet Rev. 8 — 22 April 2020 7 / 15

Nexperia 74AHC74; 74AHCT74 Dual D-type flip-flop with set and reset; positive-edge trigger 10.1. Waveforms VI nD input VM GND th th tsu tsu 1/fmax VI nCP input VM GND tW tPHL tPLH VOH nQ output VM VOL VOH nQ output VM VOL mna422 tPLH tPHL Measurement points are given in Table 8. The shaded areas indicate when the input is permitted to change for predictable output performance. V and V are typical voltage output levels that occur with the output load. OL OH Fig. 7. Clock pulse width, maximum frequency, set-up times, hold times and input to output propagation delays VI nCP input VM GND trec VI nSD input VM GND tW tW VI nRD input VM GND tPLH tPHL VOH nQ output VM VOL VOH nQ output VM VOL tPHL tPLH mna423 Measurement points are given in Table 8. V and V are typical voltage output levels that occur with the output load. OL OH Fig. 8. Set and reset pulse widths, recovery time and input to output propagation delays 74AHC_AHCT74 All information provided in this document is subject to legal disclaimers. © Nexperia B.V. 2020. All rights reserved Product data sheet Rev. 8 — 22 April 2020 8 / 15

Nexperia 74AHC74; 74AHCT74 Dual D-type flip-flop with set and reset; positive-edge trigger Table 8. Measurement points Type Input Output V V M M 74AHC74 0.5 × V 0.5 × V CC CC 74AHCT74 1.5 V 0.5 × V CC VI tW 90 % negative pulse VM VM 10 % GND tf tr tr tf VI 90 % positive pulse VM VM 10 % GND tW VCC VI VO G DUT RT CL 001aah768 For test data, see Table 9. Definitions for test circuit: C = Load capacitance including jig and probe capacitance. L R = Termination resistance should be equal to output impedance Z of the pulse generator. T o Fig. 9. Test circuit for measuring switching times Table 9. Test data Type Input Load Test V t, t C I r f L 74AHC74 V ≤ 3.0 ns 50 pF, 15 pF t , t CC PLH PHL 74AHCT74 3.0 V ≤ 3.0 ns 50 pF, 15 pF t , t PLH PHL 74AHC_AHCT74 All information provided in this document is subject to legal disclaimers. © Nexperia B.V. 2020. All rights reserved Product data sheet Rev. 8 — 22 April 2020 9 / 15

Nexperia 74AHC74; 74AHCT74 Dual D-type flip-flop with set and reset; positive-edge trigger 11. Package outline SO14: plastic small outline package; 14 leads; body width 3.9 mm SOT108-1 D E A X c y H E v M A Z 14 8 Q A 2 A 1 (A 3 ) A pin 1 index θ L p 1 7 L e w M detail X b p 0 2.5 5 mm scale DIMENSIONS (inch dimensions are derived from the original mm dimensions) UNIT mAax . A 1 A 2 A 3 b p c D (1) E (1) e H E L L p Q v w y Z (1) θ 0.25 1.45 0.49 0.25 8.75 4.0 6.2 1.0 0.7 0.7 mm 1.75 0.25 1.27 1.05 0.25 0.25 0.1 0.10 1.25 0.36 0.19 8.55 3.8 5.8 0.4 0.6 0.3 8 o 0.010 0.057 0.019 0.0100 0.35 0.16 0.244 0.039 0.028 0.028 0 o inches 0.069 0.01 0.05 0.041 0.01 0.01 0.004 0.004 0.049 0.014 0.0075 0.34 0.15 0.228 0.016 0.024 0.012 Note 1. Plastic or metal protrusions of 0.15 mm (0.006 inch) maximum per side are not included. OUTLINE REFERENCES EUROPEAN ISSUE DATE VERSION IEC JEDEC JEITA PROJECTION 99-12-27 SOT108-1 076E06 MS-012 03-02-19 Fig. 10. Package outline SOT108-1 (SO14) 74AHC_AHCT74 All information provided in this document is subject to legal disclaimers. © Nexperia B.V. 2020. All rights reserved Product data sheet Rev. 8 — 22 April 2020 10 / 15

Nexperia 74AHC74; 74AHCT74 Dual D-type flip-flop with set and reset; positive-edge trigger TSSOP14: plastic thin shrink small outline package; 14 leads; body width 4.4 mm SOT402-1 D E A X c y H E v M A Z 14 8 Q A 2 (A 3 ) A pin 1 index A 1 θ L p L 1 7 detail X w M e b p 0 2.5 5 mm scale DIMENSIONS (mm are the original dimensions) UNIT mAax . A 1 A 2 A 3 b p c D (1) E (2) e H E L L p Q v w y Z (1) θ 0.15 0.95 0.30 0.2 5.1 4.5 6.6 0.75 0.4 0.72 8 o mm 1.1 0.05 0.80 0.25 0.19 0.1 4.9 4.3 0.65 6.2 1 0.50 0.3 0.2 0.13 0.1 0.38 0 o Notes 1. Plastic or metal protrusions of 0.15 mm maximum per side are not included. 2. Plastic interlead protrusions of 0.25 mm maximum per side are not included. OUTLINE REFERENCES EUROPEAN ISSUE DATE VERSION IEC JEDEC JEITA PROJECTION 99-12-27 SOT402-1 MO-153 03-02-18 Fig. 11. Package outline SOT402-1 (TSSOP14) 74AHC_AHCT74 All information provided in this document is subject to legal disclaimers. © Nexperia B.V. 2020. All rights reserved Product data sheet Rev. 8 — 22 April 2020 11 / 15

Nexperia 74AHC74; 74AHCT74 Dual D-type flip-flop with set and reset; positive-edge trigger DHVQFN14: plastic dual in-line compatible thermal enhanced very thin quad flat package; no leads; 14 terminals; body 2.5 x 3 x 0.85 mm SOT762-1 D B A A A1 E c terminal 1 detail X index area terminal 1 C e1 index area e b v C A B y1C y w C 2 6 L 1 7 Eh e 14 8 k 13 9 Dh X k 0 2 4 mm scale Dimensions (mm are the original dimensions) Unit A(1) A1 b c D(1) Dh E(1) Eh e e1 k L v w y y1 max 1 0.05 0.30 3.1 1.65 2.6 1.15 0.5 mm nom 0.02 0.25 0.2 3.0 1.50 2.5 1.00 0.5 2 0.4 0.1 0.05 0.05 0.1 min 0.00 0.18 2.9 1.35 2.4 0.85 0.2 0.3 Note 1. Plastic or metal protrusions of 0.075 mm maximum per side are not included. sot762-1_po Outline References European Issue date version IEC JEDEC JEITA projection 15-04-10 SOT762-1 MO-241 15-05-05 Fig. 12. Package outline SOT762-1 (DHVQFN14) 74AHC_AHCT74 All information provided in this document is subject to legal disclaimers. © Nexperia B.V. 2020. All rights reserved Product data sheet Rev. 8 — 22 April 2020 12 / 15

Nexperia 74AHC74; 74AHCT74 Dual D-type flip-flop with set and reset; positive-edge trigger 12. Abbreviations Table 10. Abbreviations Acronym Description CDM Charged Device Model CMOS Complementary Metal-Oxide Semiconductor ESD ElectroStatic Discharge HBM Human Body Model LSTTL Low-power Schottky Transistor-Transistor Logic MM Machine Model 13. Revision history Table 11. Revision history Document ID Release date Data sheet status Change notice Supersedes 74AHC_AHCT74 v.8 20200422 Product data sheet - 74AHC_AHCT74 v.7 Modifications: • The format of this data sheet has been redesigned to comply with the identity guidelines of Nexperia. • Legal texts have been adapted to the new company name where appropriate. • Section 5.1: Corrected pin configuration drawings (errata). • Table 4: Derating values for P total power dissipation updated. tot • Fig. 12: Package outline drawing SOT762-1 (DHVQFN14) updated. 74AHC_AHCT74 v.7 20150421 Product data sheet - 74AHC_AHCT74 v.6 Modifications: • Table 7: minimum f values at 3.0 V to 3.6 V for 74AHC74 corrected (errata). max 74AHC_AHCT74 v.6 20141020 Product data sheet - 74AHC_AHCT74 v.5 Modifications: • Table 3 corrected (errata). 74AHC_AHCT74 v.5 20080609 Product data sheet - 74AHC_AHCT74 v.4 Modifications: • The format of this data sheet has been redesigned to comply with the new identity guidelines of NXP Semiconductors. • Legal texts have been adapted to the new company name where appropriate. • Table 6: the conditions for input leakage current have been changed. 74AHC_AHCT74 v.4 20050207 Product data sheet - 74AHC_AHCT74 v.3 74AHC_AHCT74 v.3 20040429 Product specification - 74AHC_AHCT74 v.2 74AHC_AHCT74 v.2 19990923 Product specification - 74AHC_AHCT74 v.1 74AHC_AHCT74 v.1 19990805 Product specification - - 74AHC_AHCT74 All information provided in this document is subject to legal disclaimers. © Nexperia B.V. 2020. All rights reserved Product data sheet Rev. 8 — 22 April 2020 13 / 15

Nexperia 74AHC74; 74AHCT74 Dual D-type flip-flop with set and reset; positive-edge trigger injury, death or severe property or environmental damage. Nexperia and its 14. Legal information suppliers accept no liability for inclusion and/or use of Nexperia products in such equipment or applications and therefore such inclusion and/or use is at the customer’s own risk. Quick reference data — The Quick reference data is an extract of the Data sheet status product data given in the Limiting values and Characteristics sections of this document, and as such is not complete, exhaustive or legally binding. Document status Product Definition Applications — Applications that are described herein for any of these [1][2] status [3] products are for illustrative purposes only. Nexperia makes no representation Objective [short] Development This document contains data from or warranty that such applications will be suitable for the specified use data sheet the objective specification for without further testing or modification. product development. Customers are responsible for the design and operation of their applications and products using Nexperia products, and Nexperia accepts no liability for Preliminary [short] Qualification This document contains data from any assistance with applications or customer product design. It is customer’s data sheet the preliminary specification. sole responsibility to determine whether the Nexperia product is suitable Product [short] Production This document contains the product and fit for the customer’s applications and products planned, as well as data sheet specification. for the planned application and use of customer’s third party customer(s). Customers should provide appropriate design and operating safeguards to minimize the risks associated with their applications and products. [1] Please consult the most recently issued document before initiating or completing a design. Nexperia does not accept any liability related to any default, damage, costs [2] The term 'short data sheet' is explained in section "Definitions". or problem which is based on any weakness or default in the customer’s [3] The product status of device(s) described in this document may have applications or products, or the application or use by customer’s third party changed since this document was published and may differ in case of customer(s). Customer is responsible for doing all necessary testing for the multiple devices. The latest product status information is available on customer’s applications and products using Nexperia products in order to the internet at https://www.nexperia.com. avoid a default of the applications and the products or of the application or use by customer’s third party customer(s). Nexperia does not accept any liability in this respect. Definitions Limiting values — Stress above one or more limiting values (as defined in Draft — The document is a draft version only. The content is still under the Absolute Maximum Ratings System of IEC 60134) will cause permanent internal review and subject to formal approval, which may result in damage to the device. Limiting values are stress ratings only and (proper) modifications or additions. Nexperia does not give any representations or operation of the device at these or any other conditions above those warranties as to the accuracy or completeness of information included herein given in the Recommended operating conditions section (if present) or the and shall have no liability for the consequences of use of such information. Characteristics sections of this document is not warranted. Constant or repeated exposure to limiting values will permanently and irreversibly affect Short data sheet — A short data sheet is an extract from a full data sheet the quality and reliability of the device. with the same product type number(s) and title. A short data sheet is intended for quick reference only and should not be relied upon to contain Terms and conditions of commercial sale — Nexperia products are detailed and full information. For detailed and full information see the relevant sold subject to the general terms and conditions of commercial sale, as full data sheet, which is available on request via the local Nexperia sales published at http://www.nexperia.com/profile/terms, unless otherwise agreed office. In case of any inconsistency or conflict with the short data sheet, the in a valid written individual agreement. In case an individual agreement is full data sheet shall prevail. concluded only the terms and conditions of the respective agreement shall apply. Nexperia hereby expressly objects to applying the customer’s general Product specification — The information and data provided in a Product terms and conditions with regard to the purchase of Nexperia products by data sheet shall define the specification of the product as agreed between customer. Nexperia and its customer, unless Nexperia and customer have explicitly agreed otherwise in writing. In no event however, shall an agreement be No offer to sell or license — Nothing in this document may be interpreted valid in which the Nexperia product is deemed to offer functions and qualities or construed as an offer to sell products that is open for acceptance or the beyond those described in the Product data sheet. grant, conveyance or implication of any license under any copyrights, patents or other industrial or intellectual property rights. Export control — This document as well as the item(s) described herein Disclaimers may be subject to export control regulations. Export might require a prior Limited warranty and liability — Information in this document is believed authorization from competent authorities. to be accurate and reliable. However, Nexperia does not give any Non-automotive qualified products — Unless this data sheet expressly representations or warranties, expressed or implied, as to the accuracy states that this specific Nexperia product is automotive qualified, the or completeness of such information and shall have no liability for the product is not suitable for automotive use. It is neither qualified nor tested in consequences of use of such information. Nexperia takes no responsibility accordance with automotive testing or application requirements. Nexperia for the content in this document if provided by an information source outside accepts no liability for inclusion and/or use of non-automotive qualified of Nexperia. products in automotive equipment or applications. In no event shall Nexperia be liable for any indirect, incidental, punitive, In the event that customer uses the product for design-in and use in special or consequential damages (including - without limitation - lost automotive applications to automotive specifications and standards, profits, lost savings, business interruption, costs related to the removal customer (a) shall use the product without Nexperia’s warranty of the or replacement of any products or rework charges) whether or not such product for such automotive applications, use and specifications, and (b) damages are based on tort (including negligence), warranty, breach of whenever customer uses the product for automotive applications beyond contract or any other legal theory. Nexperia’s specifications such use shall be solely at customer’s own risk, Notwithstanding any damages that customer might incur for any reason and (c) customer fully indemnifies Nexperia for any liability, damages or failed whatsoever, Nexperia’s aggregate and cumulative liability towards customer product claims resulting from customer design and use of the product for for the products described herein shall be limited in accordance with the automotive applications beyond Nexperia’s standard warranty and Nexperia’s Terms and conditions of commercial sale of Nexperia. product specifications. Right to make changes — Nexperia reserves the right to make changes Translations — A non-English (translated) version of a document is for to information published in this document, including without limitation reference only. The English version shall prevail in case of any discrepancy specifications and product descriptions, at any time and without notice. This between the translated and English versions. document supersedes and replaces all information supplied prior to the publication hereof. Trademarks Suitability for use — Nexperia products are not designed, authorized or warranted to be suitable for use in life support, life-critical or safety-critical Notice: All referenced brands, product names, service names and systems or equipment, nor in applications where failure or malfunction trademarks are the property of their respective owners. of an Nexperia product can reasonably be expected to result in personal 74AHC_AHCT74 All information provided in this document is subject to legal disclaimers. © Nexperia B.V. 2020. All rights reserved Product data sheet Rev. 8 — 22 April 2020 14 / 15
